• Description
     4M0 698 151 AA
     HR1807
     Brake Pad Set
     SET

    Front Axle
    Width : 194.3 mm
    Height : 73.9 mm
    Thickness : 15.8 mm

Brake Pad Set:4M0 698 151 AA
Model Engine Chassis Type CYL year
AUDI A4 (8W2, B9)  5/16 - /
AUDI A4 Allroad (8WH, B9)  5/16 - /
AUDI A4 Avant (8W5, B9)  5/16 - /
AUDI A5 (F53)  6/17 - /
AUDI A5 Convertible (F57)  6/17 - /
AUDI A5 Sportback (8TA)  9/09 - 1/17
AUDI A5 Sportback (F5A)  9/16 - /
AUDI A6 (C8, 4A2)  2/18 - /
AUDI A6 Avant (C8, 4A5)  5/18 - /
AUDI A7 Sportback (4KA)  0/17 - /
AUDI A8 (4N2, 4N8)  6/17 - /
AUDI Q5 (FYB)  7/17 - /
AUDI Q7 (4MB)  4/16 - /
AUDI Q8 (4MN)  5/18 - /
VOLKSWAGEN TOUAREG (CR7)  5/18 - /

Application

AUDI Q7 2017-


  • Recommends every 5,000 km check Brake System
    ensure the normal operation of the braking system
  • Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
  • Rear brakes is recommended to replace within 5-7 km
  • Replace the Disc brake when follow situation happen:
  • 1.Sensor alarm;
  • 2.Friction materials thickness less than 3mm;
  • 3.Friction materials becomes contaminated with brake fluid;
  • 4.Uneven wear within a set;
  • Replace the brake rote when follow situation happen:
  • 1.Vibrate when braking;
  • 2.Car vehicle performance more than 60000Km and braking unstable;
  • 3.Disc brake thickness wear more than 2mm;
